Technical Parameters
-
-
-
-
-
- Product Name Compound electric heating heat washer
- Brand BOHUA
- Model BH30-1062C
- Production Standards GBT38144.1/2-2019, US ANSI Z358.1-2014
- Material 304 Stainless Steel+ABS外壳 保温棉
- Protection Level IP65 (Optional)
- Function Eyewash + Shower + Electric Heating + Electric Heating
- Nominal Pressure 1.0Mpa
- Explosion-proof Grade Exd IICT6 (Optional)
- Work Pressure 0.2~0.4Mpa
- Eyewash Flow ≥11.4L/min
- Shower Flow ≥76L/min
- Water Inlet Size 1-1/4 internal thread, height 1580MM
- Drain Size 1-1/4 internal thread, height 135MM
- Gross Weight 39KG
- Net Weight 37KG
- Use Medium Daily water at room temperature that meets hygienic standards
- Eyewash Nozzle Fixed soft rubber dust cover, not easy to lose, soft rubber design is not easy to hurt the eyes. Built-in multi-layer filter, effectively filter impurities in the water, making the water flow into a foamy water column.
- Applicable Temperature This product is suitable for use in environments that require antifreeze. The heater can effectively increase the eyewash water outlet temperature.
- Applicable Places It is widely used in nuclear energy, power plants, pharmaceuticals, medical treatment, chemical industry, petroleum, shipping, electronics, metallurgy, printing and dyeing, education, scientific research and other units, industries or fields.
-
Product Details
